Common Product Types
- Tri-clamp gaskets / sanitary gaskets
- PTFE (Teflon) encapsulated o-rings
- X-rings
- Rubber washers
- Custom rubber components
- Custom plastic components
- O-rings (standard, micro, and giant sizes depending on application)
Common Industry Requirements
- FDA compliant materials per CFR 21.177.2600
- USP Class VI certified materials
- Metal detectable materials
- Animal Derived Ingredients (ADI) free materials
- Clean room manufacturing and packaging
USP Class VI Specification
The United States Pharmacopeia (USP) is a non-government organization that promotes public health by establishing state-of-the-art standards to ensure the quality of medicines and other health care technologies. While this organization is concerned with the pharmaceutical and bio-technology industries, many manufacturers of hygienic equipment will be designing multipurpose designs that may be used in a range of different industry sectors. Standards are published in the US Pharmacopeias and the National Formulary (USP NF). Compliance to USP Class VI is often requested by end users. Testing for compliance involves an assessment of the effects of the material, and extractable, on tissue.
United States Pharmacopeia USP 26, NF21, 2003 Class VI Two types of biological reactivity test are applicable to elastomers, plastics and polymeric materials; Chapter <87> involves in vitro testing and Chapter <88> involves in vivo testing.
An additional requirement some of our O-Rings and materials meet is free from animal derived ingredients (ADI-free).
Pharmaceutical, food and water processing industries present many demanding sealing applications. Unlike other industries where chemical or temperature resistance is the key seal selection criteria, food and pharmaceutical applications can add the requirement of cleanliness and regulatory challenges. Elastomer seals used in process equipment, pumps, valves, pipe work, couplings, reaction vessels and bulk containers must be able to cope with a wide range of process media, potent active pharmaceutical ingredients (APIs) and aggressive cleaning and sterilizing processes. In addition, seals must be compliant with a growing range of legislative manufacturing regulations and hygiene standards. Marco Rubber offers a comprehensive range of sealing solutions compliant with the requirements of the Food and Drug Administration (FDA), United States Pharmacopeia - Class VI (USP Class VI) and 3-A Sanitary standards, as well as Good Manufacturing Practice (GMP) quality criteria. In addition to industry-standard Elastomers such as EPDM and silicone, Marco offers Markez® Perfluoroelastomers for extreme operating conditions, we also offer a range of FKM materials that are compliant or approved to different regulatory standards.
Popular Marco Compounds for Medical and Pharma Applications
Compound # | Datasheet | Material | Hardness (Shore A) | Color | Low Temp °F (°C) | High Temp °F (°C) | FDA* | USP Class VI** | NSF61 | USDA 3A | Metal Detectable | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
E1000 |  | EPDM | 70 | Black | -65 (-54) | 300 (149) | Peroxide cured EPDM, Different Durometer, KTW, WRAS standards available | |||||
E1074 | | EPDM | 70 | White | -65 (-54) | 300 (149) | Wide range of compliance | |||||
E1080 | | EPDM | 70 | Black | -40 (-40) | 250 (121) | Wide range of compliance | |||||
E1097 | | EPDM | 70 | Black | -65 (-54) | 300 (149) | Formulated for Chloramine Resistance. Can be manufactured in custom shapes with minimal setup charge. | |||||
B1002 | | NBR | 70 | Black | -65 (-54) | 300 (149) | Available in many durometers and colors | |||||
B1039 | | NBR | 70 | White | -30 (-34) | 250 (121) | Available in many durometers and colors | |||||
B1058 | | NBR | 70 | Black | -30 (-34) | 250 (121) | KTW, WRAS and other standards available. | |||||
B1105 | | NBR | 70 | Black | -30 (-34) | 250 (121) | Metal detectable for contamination detection sensors(additional colors available) | |||||
S1000 | | VQM | 70 | Orange | -70 (-57) | 400 (204) | Available in many durometers and colors | |||||
S1020 | | VQM | 70 | Clear Translucent | -75 (-59) | 400 (204) | Clear Translucent, available in many durometer and color choices. | |||||
S1037 | | VQM | 70 | Clear Translucent | -75 (-59) | 400 (204) | Clean room manufactured, platinum cured (specific base materials and cleanroom packaging options available) | |||||
S1083 | | VQM | 70 | Clear Translucent | -65 (-54) | 400 (204) | Commercial manufactured, platinum cured (cleanroom manufacturing and packaging options available) | |||||
S1146 | | VQM | 70 | White | -75 (-59) | 480 (249) | Cleanroom manufactured, Lower cost than clear | |||||
V1039 | | FKM | 75 | White | -15 (-26) | 437 (225) | Cleanroom manufacturing and packaging options available | |||||
V1118 | | FKM | 70 | White | -15 (-26) | 437 (225) | Steam Resistant Terpolymer, Also available in black | |||||
V1148 | | FKM | 70 | Black | -15 (-26) | 392 (200) | Metal detectable for contamination detection(additional colors available) | |||||
Z1416 | | FFKM | 80 | Black | 1 (-17) | 610 (321) | FDA compliant, higher temperature resistance, wide chemical compatibility. Compare to Kalrez® 6230, Kalrez® LS222 | |||||
Z1703 | | FFKM | 75 | Black | 5 (-15) | 525 (274) | Low cost performance value, nearly universal chemical compatibility, acid, amines, solvents, compression set resistance, FDA compliant and USP Class VI medical grade. Compare to Kalrez® 6230, Kalrez® LS222 | |||||
Z1318 | | FFKM | 75 | White | 5 (-15) | 500 (260) | USP Class VI and FDA compliant white FFKM with wide range compatibility. Compare to Kalrez® 6221, Kalrez® LS205, Chemraz® 625 |
*FDA compliance per 21 CFR 177.2600 parts A-D, E&F approved compounds available upon request.
**USP <87> and USP <88> approved compounds available upon request.
The information on this page is to the best of our knowledge accurate and reliable. However, Marco Rubber makes no warranty, expressed or implied, that parts manufactured from this material will perform satisfactorily in the customer's application. It's the customer's responsibility to evaluate parts prior to use.
The temperature ranges presented on this page are approximations for dry air service only and should not be used to determine design specifications or end-use temperature limits. Actual temperature range of a compound in an end-use application is highly dependent on part type, hardware configuration, applied forces, chemical media, pressure and thermal cycling effects, and other factors. The most practical way of determining an end-use temperature range is testing in the actual application conditions. Consult a Marco Engineer for more details.
